Cattle drinking bowl

No.1017 - No.1018

Cattle drinking bowl


Stainless steel drinking bowl

  • material: 1.0mm thickness SUS304 stainless steel;
  • Smooth edge protect animal cutting use for cattle & horse
  • Size: L25*W25*D10 cm. Weight:1500g


Plastic float valve parameters (Figure 3-Figure 4)

DN15B:

  • Mode:1/2"  plastic float valve DN15B
  • Install Size:196mm(Maximum)
  • Thread:1/2" Inch
  • Body Material:ABS(Acrylonitrile Butadiene Styrene plastic)
  • Float Ball Material:PE(Polyethylene)
  • Seals Material:SR(Silicon Rubber)
  • Working Pressure:0.05-1.2 Mpa(0.1Mpa=1Bar=14.5Psi)
  • Working Temperature:0-70℃

DN15H:

  • Install Size:177.00mm(Maximum)
  • Thread:1/2" Inch
  • Body:ABS(Acrylonitrile Butadiene Styrene plastic)
  • Float Ball:PE(Polyethylene)
  • Seals:SR(Silicon Rubber)
  • O' Ring:  NBR(Nitrile Butadiene Rubber)
  • Working Pressure:0.01-1.2 Mpa(0.1Mpa=1Bar=14.5Psi)
  • Working Temperature:0-70℃
